    P7.62 244mm x 244mm indoor full color LED display Module 1/16 Scan

    Ask Lasest Price
    Brand Name : SRYLED
    Model Number : SRYLED - IFM - P7.62
    Certification : CE, LVD, RoHS
    Price : US$14 - 15 / PCS
    Payment Terms : T/T, PayPal, Western Union
    Supply Ability : 1,000 PCS per Month
    Delivery Time : 5 - 7 Work Days
    • Product Details
    • Company Profile

    P7.62 244mm x 244mm indoor full color LED display Module 1/16 Scan


    P7.62 244mm x 244mm indoor full color LED display Module 1/16 Scan

    Decription:


    High Definition P7.62 Indoor 244mm x 244mm Full Color LED Module 1/16 Scan.


    Features:
    1. Best viewing distance
    7m - 70m
    2. Best viewing angle
    H: 120°, V: 120°
    3. Max. power consumption
    600W/sqm
    4. Ave. power consumption
    200W/sqm

    Specification:


    Pixel Pitch

    7.62mm

    Pixel Density

    17,222dots/sqm

    Tube Chip Color

    Full Color

    Color Configuration

    1R1G1B 3in1

    LED Encapsulation

    SMD3528

    Module Size

    244mm x 244mm

    Module Resolution

    32dots x 32dots

    Cabinet Weight15kg

    Drive Duty

    1/6 Constant Current

    Brightness

    >6,500nits

    Viewing Distance

    7m - 70m

    Viewing Angle

    H: 120°, V: 120°

    Refresh Rate

    2,000HZ

    Frame Rate

    120frame/sec

    Grey Grade

    256levels of Each Color

    Color Grade

    16.7M

    Power Input

    AC110V/ 220V/ 50HZ

    Max Power Consumption

    600W/sqm

    Ave. Power Consumption

    200W/sqm

    Storage Temperature

    -40℃ - +80℃

    Working Temperature

    -20℃ - +60℃

    WaterproofIP65

    Blind Spot Rate

    <1/10,000

    MTBF

    >10,000 Hours

    Life Span

    >100,000 Hours

    Operating Humidity

    10% - 95%

    Control System

    Synchronous, Asynchronous

    Operating System

    Win 98, Win2000, XP, 07.etc

    Input Source

    All Format (AVI, MPEG,VOB, RM, etc)

    Certificate

    CE, LVD, RoHS


    Application:

    Widely using for music concert, theater, stadium, showroom, stage, monitoring room and etc.

    Pictures:



    Competitive Advantages:

    1. Vivid and brilliant color, sharp and smooth images.


    2. Superb performance/price ratio solution for rental market.


    3. 24/7 professional after sales service, and on-site service is available.


    4. Support different shapes installation: Flat and curved ,create infinite stage styles.
