    P2.5 Indoor HD Full Color Die-casting Aluminum Cabinet LED Display, Portable Design Display

    Ask Lasest Price
    Brand Name : CNSRYLED
    Model Number : SRYLED-IFS-P2.5
    Certification : CE, LVD, RoHS
    Price : US$ 1,460 - 1,560 / Square Meter
    Payment Terms : T/T, Western Union, PayPal
    Supply Ability : 1,000 Square Meter per Month
    Delivery Time : 10 - 12 Working Days
    • Product Details
    • Company Profile

    P2.5 Indoor HD Full Color Die-casting Aluminum Cabinet LED Display, Portable Design Display

    P2.5 Indoor HD Full Color Die-casting Aluminum Cabinet LED Display, Portable Design Display


    Quick Info.

    Brand: CNSRYLED

    Pixel Pitch: 2.5mm

    LED Encapsulation: SMD2020

    Color Configuration: 1R1G1B 3in1

    Module Size: 160mm x 160mm

    Cabinet Size: 480mm x 480mm

    Cabinet Material: Die-casting Al

    Warranty: 2 Full Years

    Certifications: CE, LVD, RoHS

    Place of Origin: Shenzhen, China


    Specs.

    ParameterP2.5
    Module
    Pixel Configuration1R1G1B SMD2020
    Pixel Pitch2.5mm
    Module Resolution(W×H)64dots x 64dots
    Module Size160mm x 160mm
    Module Weight0.18kg
    Max Power Consumption25W
    Cabinet(Panel)Module Qty9pcs
    Cabinet Resolution(W×H)192×192dots
    Cabinet Size480mm x 480mm
    Weight of One Cabinet7.8kg
    Cabinet Flatness≤0.2mm
    Cabinet MaterialDie-casting Cabinet
    Optical ParametersBrightness Calibration by Per DotYes
    White Balance Brightness≥1,500nits
    Color Temperature3200K--9300K(adjustable)
    View AngleHorizontal 110°, Vertical 110°
    Brightness Uniformity≥97%
    Max.Contrast4,000:1

    Electrical Parameters

    Max Power Consumption(㎡)225W/㎡
    Average Power Consumption(㎡)180W/㎡
    Input VoltageAC 110V - 220V ± 15%
    Processing PerformanceDriving Mode1/32scan
    Frame Rate(Hz)120frame/sec
    Refresh Frequency(Hz)≥2,000HZ
    Using ParametersBest Viewing Distance(m)2.5 - 25m
    Lifetime≥100,000hrs
    Working Temperature-20°C - + 50°C
    Stored Temperature-30°C - + 60°C
    Working Humidity(RH)10% - 90%(no dew formation)
    Stored Humidity(RH)10% - 95%(no dew formation)
    WaterproofNO
    Statement: Product parameters table for reference only, the specific subject to the actual.

    Competitive Advantages

    1. HD play, delicate and clear.

    2. Excllent encapsulte effect. Strong adaption to environment.

    3. Higher cost performance, lower maintenance cost.

    4. Small chip body combined with black mask, generating higher contrast ratio.

    5. Strictly screening same LED wavelength, brightness voltage and etc to ensure the consistency of the whole screen.

    6. High quality driving IC, combined with the control system which has more than 14bit processing, effecting a higher refresh rate.

    7. High quality driving IC,combined with the control system which has more than 14bit processing, effecting a higher gray level.

    8. Easy and fast to install and disassemble, without any tools.


    Application

    Business Organizations


    Supermarket, large-scale shopping malls, exclusive agency, chain shops, largescale sales, starrated hotels, restaurants, travel agencies, pharmacy.


    Financial Organizations

    Banks, negotiable securities, funds, insurance companies, pawnshops;

    Non-profit Organizations: Telecommunications, post offices, hospital,

    schools;


    Public Places

    Subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas,offices, commercial buildings, model rooms, property brokers;


    Entertainments

    Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course
